22 DR ® RAPIDFIRE™ LOG SPLITTER
Chapter 6: Parts Lists and Schematic Diagrams
Parts List - TOW BAR AND AXLE ASSEMBLY
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 11239 Washer, Flat, 3/8", USS
2 15043 Bolt, HHCS, 3/8-16 X 1-1/4", Gr5
3 11075 Nut, Nylon Lock, 3/8-16, ZP
4 29469 Cradle, Standard Acc
5 11073 Nut, Nylon Lock, 1/4-20, ZP
6 18064 Washer, .8" ID, 1.5" OD X .11"
7 15745 Washer, Flat, 5/8", USS
8 21155 Pin, Snap Safety, 3/8" X 2.75"
9 19295 Clevis Hitch
10 16003 Pin, Hitch Clip, 1/2" To 9/16", .12" Wire
11 21154 Pin, Clevis, 1/2" X 3.50" Lg., ZP
12 30416 Stand, Tube
13 30433 Premium Knobby Wheel Assembly, 4.80
4.00 8
14 30427 Towbar, Rapid Fire
15 18655 Pin, Cotter, 3/16" X 2.0"
16 30428 Axle
Ref# Part# Description
17 11238 Washer, Flat, 1/4", USS
18 11983 Bolt, HCS, 1/4-20 X 3/4", Gr2, ZP
19 18031 Bolt, BHCS, 1/4-20 X 5/8", ZP
20 29463 Guard, Belt, Center
21 29466 Guard, Belt, Right
22 29465 Guard, Belt, Left
23 29453 Bracket, Cover
24 25044 Label, Warning, Pinch Point, 3.5" x1"
25 24182 Label, Warning, Rotating Parts
26 27576 Label, Splitter, Rapidfire
27 29523 Label, Serial #, Barcode
28 18744 Label, Dr Logo, 10", Round
29 29499 Label, Warning, Cover, Belt
30 19296 Bolt, HCS, 5/8-11 X 1.75", Gr5, ZP
31 11985 Bolt, HCS, 3/8-16 X 1-1/2", Gr5, ZP
32 10131 Nut, Nylon Lock, 5/8-11
