Chapter 3 BIOS Description
1.Standard CMOS Features
1.1 Date
This option allows you to set the desired date (usually as the current day) with
the <day><month><date><year> format.
Day—weekday from Sun. to Sat., defined by BIOS (read-only).
Month—month from Jan. to Dec..
Date—date from 1
st
to 31
st
, can be changed using the keyboard.
Year—year, set up by users.
1.2 Time
This option allows you to set up the desired time (usually as the current time)
with <hour><minute><second> format.
1.3 SATA Channel 1/2/3/4/5/6,IDE Channel Master/Slave,e-SATA channel1/2
These categories identify the HDD types of 1 IDE channel installed in the com-
puter system. There are three choices provided for the Enhanced IDE BIOS:
None, Auto, and Manual. “None” means no HDD is installed or set; “Auto” means
the system can auto-detect the hard disk when booting up; by choosing “Manual”
and changing Access Mode to “CHS”, the related information should be entered
manually. Enter the information directly from the keyboard and press < Enter>:
Standard CMOS Features Menu
Award (Phoenix) BIOS can support 3 HDD modes: CHS, LBA and Large or Auto
mode.
Cylinder
number of cylinders
Head number of heads
Precomp
write pre-compensation Landing Zone landing zone
Sector
number of sectors
CHS
For HDD<528MB
LBA
For HDD>528MB & supporting LBA (Logical Block Addressing)
Large
For HDD>528MB but not supporting LBA
Auto
Recommended mode
