36
Chapter 3 BIOS Description
NB Voltage Setting
This item is used to set NB Voltage. The default voltage is 1.250V.
Pay attation to the Warning message in the “Item Help” table.
CPU VTT Voltage Setting
This item is used to set CPU VTT Voltage. The default voltage is 1.200V.
Pay attation to the Warning message in the “Item Help” table.
SB Voltage Setting
This item is used to set SB Voltage. The default voltage is 1.500V.
Pay attation to the Warning message in the “Item Help” table.
8.4 Over Clock Phase Select
Use this item to select the over clock phase. Setting values: [O.C. Disabled];
[Manual O.C.]; [Instant O.C.].
8.5 Instant OverClocking
This item is used for instant OverClocking , you may choose over clock
instantly by 5%, 10%,15%.....etc.
8.6 ***Ratio and Clock Setting***
CPU Clock Ratio Unlock
This item is used to enable or disable the CPU Clock Ratio Unlock.
CPU Clock Ratio
This item is used to set the ratio of an unlocked CPU. Using different CPU,
the setting values are different.
CPU Clock
This item allows you to adjust the CPU FSB clock.
CPU Clock vs Memory Speed
This item allows you to set the rate of CPU Clock vs Memory Speed.
System Memory Speed
This item shows the System Memory Speed.
PCI Express Clock
This item allows you to adjust the PCI Express bus clock.
PCI Clock
This item allows you to adjust the PCI bus clock. Configuration options:
[Synchronous] (Synchronous with PCI Express bus clock); [33.6 MHz]; [37.3
MHz]; [42.0 MHz].
