Pub. 42004-679L2G
M ODEL DEX-10 X AND DEX-20 X D RILLER ’ S I NTERCOM S TATIONS Page 11 of 13
f:\standard ioms - current release\42004 instr. manuals\42004-679l2g.doc
07/13
Paging
This station is capable of sending and receiving all-calls and group calls. Refer to the “All-Call” and
“Group Call” sections of the Central Switch manual for configuration details.
Alarms and Music
This station is capable of receiving alarms and music. Refer to the “Alarm” and “Music” sections of the
Central Switch manual for configuration details.
Analog Models DEX-101 and DEX-201
Intercom Communication Modes
Slave Communication - Communication between two stations can be automatically enabled during the
system start-up, or when enabled/disabled by the master station.
1. The LED on the front panel illuminates to indicate a call is in progress.
N OTE : The beacon output control is not available on this model.
2. Speak into the microphone to transmit audio.
3. Audio is broadcast over this station’s speaker when the master station user pushes the T button.
Point-to-Point Communication - Communication with this station can be enabled when another station
dials the extension of this station.
1. The LED on the front panel illuminates to indicate a call is in progress.
N OTE : The beacon output control is not available on this model.
2. Speak into the microphone to transmit audio. If necessary, talk/listen control from this station can be
controlled using the station’s footswitch input.
3. Audio is broadcast over this station’s speaker when the other station user speaks. (If necessary,
talk/listen control from the other station can be controlled using the T button on the keypad or by
using the station’s footswitch input.)
4. The calling station must terminate the call by depressing the X button.
Volume Control
Volume level adjustments for this station can be configured in the Central. Refer to the “Volume
Configuration” section of the Central Switch manual for details.
Paging
This station is capable of sending and receiving all-calls and group calls. Refer to the “All-Call” and
“Group Call” sections of the Central Switch manual for configuration details.
Alarms and Music
This station is capable of receiving alarms and music. Refer to the “Alarm” and “Music” sections of the
Central Switch manual for configuration details.
