Installation 7
© 2015 Geist GM1157 - GU PDU Instruction Manual
2.2 Mounting
Figure 1: Full-Length Bracket
Using the full-length bracket, mount PDU to rack as shown
Figure 2: Mini "L" Brackets
Using the mini “L” brackets, attach PDU to rack as shown
