Guntermann & Drunck CATCenter X systems Communicaton modules User Manual
Page 26
Guntermann & Drunck GmbH CATCenter Communication Components
Page 26
In particular, these are:
•
F3
: Add Use this key to add a new TS workstation
(see
Chapter 3.5.1.1
)
•
F4
: Delete Use this key to delete an existing TS workstation
(see
Chapter 3.5.1.2
)
•
F5
: Edit Use this key to edit an existing TS workstation
(see
Chapter 3.5.2
)
•
ESC
: Use this key to exit the current menu and return to
the Configuration menu
3.5.1.1 Creating a TS Workstation
If you want to create a new TS workstation, press the
F3
key in the
Tradeswitch Function Config submenu. The following window is opened:
A d d T r a d e s w i t c h F u n c t i o n
Name
ESC
F2: Save
Assign a unique name for this TS workstation in the NAME field. A maximum
of 14 alphanumeric characters is available to you for this purpose.
To save the changes you have made, press the
F2
key. Subsequently, you
are returned to the Tradeswitch Function Edit submenu.
Press
ESC
to exit the menu without saving the changes you have made.
3.5.1.2 Deleting a TS Workstation
You can remove a TS workstation from the CATCenter system within the
Tradeswitch Function Config submenu by pressing the
F4
key. The
following confirmation message is displayed:
