Guntermann & Drunck GmbH CATCenter Communication Components
Page 28
cursor is positioned at the first edit position. Complete your entry by pressing
ENTER . The cursor moves to the first position within the list box.
The meaning of the columns within this window is as follows:
Column 1 Key: This column lists the tradeswitch keys set to carry out
the tradeswitch function (see
Chapter 3.3 )
Column 2 Master:
The UCON (to which the physical keyboard and mouse
are connected) which acts as the TS master console
within the workstation is identified in this column
(see
Chapter 3.5.2.4 )
Column 3 Channel: This column shows whether a console or a target
has been assigned to this channel. Access this
channel using the tradeswitch keys you have
defined (see column 1).
Four different
F keys are available to you for editing tasks in the footer of the
Tradeswitch Function Edit submenu.
In particular, these are:
F9 : Console Use this key to assign a console to this TS workstation
(see Chapter 3.5.2.1 )
F4 : Delete Use this key to remove a console or target from a TS
workstation (see Chapter 3.5.2.2 )
F10 : CPU Use this key to assign a target to this TS workstation
(see Chapter 3.5.2.3 )
F6 : Edit Master Use this key to define a console as the TS master console
(see Chapter 3.5.2.4 )
These editing functions are explained in more detail in the following chapters.
All editing tasks carried out up to this point can be saved by pressing the F2
key.
Press ESC to exit the Tradeswitch Function Edit submenu. If you have
made any changes up to this point but wish to exit the Tradeswitch Function
Edit submenu without saving your changes, a warning message to that effect
will be displayed.
