Installing the Memory
The MB945 motherboard supports four DDR3 memory sockets for a
maximum total memory of 8GB in DDR memory type. It supports
DDR3 800/1066.
Basically, the system memory interface has the following features:
Supports two 64-bit wide DDR data channels
Available bandwidth up to 6.4GB/s (DDR3 800) for single-channel
mode and 12.8GB/s (DDR3 800) in dual-channel mode.
Supports 512Mb, 1Gb DDR3 technologies.
Supports only x8, x16, DDR3 devices with four banks
Supports only unbuffered DIMMs
Supports opportunistic refresh
Up to 32 simultaneously open pages (four per row, four rows
maximum)
Dual Channel Memory Configuration
If you want to operate the Dual Channel Technology, please note the
following explanations due to the limitation of Intel chipset
specifications.
1. Dual Channel mode will not be enabled if only one DDR II memory
module is installed.
2. To enable Dual Channel mode with two or four memory modules (it is
recommended to use memory modules of identical brand, size, chips,
and speed), you must install them into DIMM sockets of the same color.
The following is a Dual Channel Memory configuration table:
(DS: Double Side, SS: Single Side)
DDRIII1 DDRIII2 DDRIII3 DDRIII4
2Memory Modules DS/SS X DS/SS X
X DS/SS X DS/SS
4Memory Modules DS/SS DS/SS DS/SS DS/SS
