INTRODUCTION
MB945 User’s Manual 3
Specifications
Product Name MB945
Form Factor ATX
CPU Type Intel® Core™2 Duo Processor E8000 and E7000 series
Intel® Core™2 Quad
Processor Q9000 series
Intel® Core™2 Extreme
Processor QX9000 series
CPU Speed Up to 3.0 GHz or higher
CPU FSB 800/1066/1333MHz FSB
L2 Cache Up to 12MB
Green /APM APM1.2
CPU Socket LGA775
Chipset Intel Eaglelake:Q45 + ICH10DO Chipset
GMCH : AC82Q45, 34mm x 34mm, 1254-pin FC-BGA
ICH10DO: AF82801JDO, 31mm x 31mm, 676-pin mBGA
BIOS Award BIOS, support ACPI Function
Memory DDRIII 800/1066MHz
- DIMM x 4 (w/o ECC), Max. 8GB
VGA
Q45 built-in Intel gen.5.0 Graphics Media Accelerator , supports
DirectX10 (Vista), Integrated DP, DVI, VGA SDVO; Dual
Independent Display
LAN
1. ICH10DO Gigabit MAC + PHY:
• Intel 82567LM Gigabit Ethernet PHY
2. Intel 82574L PCI-e Gigabit LAN controller x1 (MB945F)
USB ICH10DO built-in USB 2.0 host controller, supports 12 ports
Serial ATA ICH10DO built-in SATA controller, supports 6 ports
Parallel IDE/ CF - JMicron JM368 (PCI-e to PATA) x1 for 1 PATA channel for
IDE & CF: IDE 40 pin and vertical CF socket x 1
Audio ICH10DO built-in HD Audio controller: ALC888 w/ 7.1 channels
LPC I/O Winbond W83627DHG: IrDA x1, COM1 (RS232), COM2
(RS232/422/485), Hardware monitor (3 thermal inputs,
4 voltage monitor inputs, VID0-4 & 2 Fan Headers)
- Fintek 81216G for COM 3. COM4
Digital IO 4 in & 4 out
TPM1.2 ICH10DO built-in iTPM version1.2 controller by firmware
Keyboard/Mouse Supports PS/2 Keyboard/Mouse connector
Expansion Slots PCI slot x4, PCI-e (x1) slot x1 and PCI-e (x16) slot x1, ISA slot x1
Edge Connector PS/2 Connector x1 for keyboard/mouse
Gigabit LAN RJ-45 + dual USB stack connector x2
DB9 + DB15 stack connector x1 for COM 1 & VGA
DB25 connector x1 for SPP/ECP/EPP
RCA Jack 3x2 for HD Audio
Onboard
Header/Connector 40-pin box-header x1 for IDE
34-pin box-header x1 for FDD
SATA connector x6 for 6 ports SATAI/SATAII
CF connector x1 for CF Card
2x5-pin pin-header x4 for 8 ports USB
2x5-pin pin-header x1 for front panel audio
2x5-pin pin-header x3 for COM2/3/4
2x5-pin pin-header x1 for Digital IO
Watchdog Timer Yes (256 segments, 0, 1, 2…255 sec/min)
System Voltage +5V, +3.3V, +12V, -12V, 5VSB (2A)
Other LAN Wakeup
RoHS Yes
Board Size 305mm x 244mm (12” x 9.5”)
