Operation
Disinfect contaminated surfaces of the curing light as
well as light probes and anti-glare cones before each
use. Furthermore, make sure that the stipulated light
intensity permits adequate polymerization. For that
purpose, check the light probe for contamination and
damage as well as the light intensity at regular intervals.
Selecting the curing time
The curing time can be individually set using the time
selection button. Users may choose between 10, 15, 20
and 30 seconds.
Observe the Instructions for Use of the material applied
when selecting the curing time. The curing recommenda-
tions for composite materials apply to all shades and, if
not mentioned otherwise in the Instructions for Use, to a
maximum layer thickness of 2 mm. Generally, these
re commendations apply to situations where the emission
window of the light probe is placed directly over the
material to be polymerized. Increasing the distance
between the light source and the material will require
the curing time to be extended accordingly. For instance,
if the distance to the material is 9 mm, the effective light
output is reduced by approx. 50%. In this case, the
recommended curing time has to be doubled.
Start button
Time selection
button
Curing times 1.100 mW/cm 2 ± 10%
Restorative materials
Composites
• 2 mm
1)
Tetric EvoCeram / Tetric EvoFlow / IPS Empress Direct /
Tetric / Tetric Basic White / Tetric N-Ceram / Tetric N-Flow
10 s
Heliomolar / Heliomolar HB / Heliomolar Flow
All conventional composites
15 s
• 4 mm 2)
Tetric EvoCeram Bulk Fill / Tetric Basic White
10 s
Compomers 3)
Compoglass F / Compoglass Flow
20 s
Indirect restorations /
cementation materials
Variolink Base 4) / Variolink Veneer /
Variolink N Base 4) / Variolink N Clear Veneer
per mm ceramic:
10 s per surface
Variolink Ultra 5)
Dual Cement 5) / Variolink II 5)
per mm ceramic:
10 s per surface
Adhesives
Syntac / Heliobond / ExciTE F / ExciTE F DSC / AdheSE / AdheSE One F /
Tetric N-Bond / Tetric N-Bond Self-Etch
10 s
Temporary materials
Systemp.inlay/onlay / Fermit / Fermit N 10 s
Telio CS Link / Systemp.link 10 s per surface
Miscellaneous
Helioseal / Helioseal F / Helioseal Clear 10 s
Monopaque
MultiCore Flow / MultiCore HB
IPS Empress Direct Opaque
IPS Empress Direct Color
20 s
Telio Add-On Flow 15 s
Telio Stains
Heliosit Orthodontic
Vivaglass Liner
10 s
1) Applies to a maximum layer thickness of 2 mm and provided that the Instructions for Use of
the respective material do not state any other recommendation (might be the case e.g. with
dentin shades)
2) Applies to a maximum layer thickness of 4 mm and provided that the Instructions for Use of
the respective material do not state any other recommendation (might be the case e.g. with
dentin shades)
3) Applies to a maximum layer thickness of 3 mm
4) Applies to light-curing (use of the base past only)
5) Applies to dual-curing
