English - 17
Chapter 6 Control Panel/Remote Control and
Setting Menu
6.1 Functions of control panel and remote control
<Remark> The below functions are listed alphabetically
Name Function Descriptions Operation
Turn on and off the Document Camera.
*Press and hold for 5 ~ 10 seconds to turn
off
Remote control/
Control panel
g,h,i,j
Move up, down, left or right to select the
needed function.
Remote control/
Control panel
FOCUS
Auto focus. Either sides of
the lens
AUTO TUNE Automatically adjust the image to have the
best brightness and focusing performance.
Remote control/
Control panel
BRT+/-
/
Adjust the brightness of the image.
Remote control
CAPTURE Capture images to USB disk (priority) or
internal memory.
Control panel
CAPTURE
/DEL
Capture and save images to USB disk
(priority) or internal memory while
displaying live images.
Delete files from the USB disk (priority) or
internal memory while reading the stored
files (in Playback mode).
Remote control
ENTER Activate/Enter functions.
Remote control
ENTER /
FREEZE
Live image: Freeze the image
OSD mode: Activate/Enter functions
Control panel
