42
ENGLISH
System Information
MAC address is displayed.
Setting items Setting details
MAC Address
Displays the MAC address. Displays the MAC address.
Remote control operation
buttons
Displaying the menu
Cancel the menu
Move the cursor
(Up/Down/Left/Right)
Decision the setting Return to previous menu
Audio Setting
Speaker Setting
Default settings are underlined.
The settings for audio signals output from the analog 7.1ch output terminals are made.
• This setting is effective for analog audio output only.
• Initial setting for the speaker is 7.1ch. For multi-channel playback, be sure to make this setting.
Setting items Setting details
Configuration
Set the number of speakers
to be used. 2.1ch : Front L and R speakers are used.
3.1ch : Front L and R and a center speakers are used.
4.1ch : Front L and R and surround L and R speakers are used.
5.1ch : For normal 5.1-channel surround system.
6.1ch : A surround back speaker is added to the 5.1-chananel surround
system (The surround back speaker is output from SBL ch.).
7.1ch : For normal 7.1-channel surround system
The settings below can be made for all settings from “2.1ch” to “7.1ch”.
• Speaker size: Large or Small
• Subwoofer: Used or not used
None : Subwoofer is not connected.
LFE : Adds the low frequency signal of the channel for which the
speaker size is set to “small” to the subwoofer signal and outputs it.
LFE+Main : Adds the low frequency signal of all channels to the
subwoofer signal and outputs it.
• Sound level ：0 dB to 10 dB (initial setting: 0 dB)
• Distance ：0 m to 10 m (initial setting: 3 m)
n When 2.1ch is selected
Lt/Rt : For selecting down-mixing of multi-channel audio input of DTS-
HD, DTS-Digital Surround, Dolby Digital Plus or Dolby Digital audio to
a format supporting Dolby surround. If the unit is connected to an AV
amplifier supporting Dolby surround, surround sound can be enjoyed.
Stereo : Multi-channel sound is down-mixed to 2-channel stereo.
NOTE
“Lt/Rt” and “Stereo” are effective only when “2.1ch” is selected.
Test Tone Check the speaker settings, using a test tone.
Automatically switches the test tone output speaker.
Press
ENTER to manually set the values for the desired speaker.
NOTE
• Before starting the test tone, reduce the volume setting of the amplifier
to an appropriate level.
• The test tone is output soon after ENTER is pressed.
• Pressing RETURN stops the test tone.
