CB-7080 & CB-7080D Counter/Timer User's Guide $AA0H
2-9
$AA0H
Description: Reads the minimum input signal width at high level. Refer to " Digital filter setting " for more
information.
Syntax: $AA0H[chk](cr)
$ A delimiter character
AA 2-character HEX module address, from 00 to FF
[chk] 2-character checksum. If checksum is disabled, no [chk].
(cr) 0x0D
Response :
Valid response !AA(data)[chk](cr)
Invalid response ?AA[chk](cr)
No response Syntax error, communication error or address error
! A delimiter character indicating a valid response
? A delimiter character indicating an invalid response
AA 2-character HEX module address
(data) 5-character decimal value for min. width at high level. The unit is microseconds
(µs) and the range can be from 2 µs to 65535 µs.
[chk] 2-character checksum. If checksum is disabled, no [chk].
(cr) 0x0D
Examples :
Min. width = 10

s
command $010H(cr)
response !0100010(cr)
Min. width = 1000

s = 1 ms
command $020H(cr)
response !0201000(cr)
