8 LEDs
The module has four LEDs.
8.1 Status LED
This turn red for 1 second when power is applied and then turn green when the FPGA code has
been loaded correctly.
The LED is green
• the module is programmed and functioning normally.
The LED is orange
• the module is not programmed or is in the process of being programmed
The LED is red
• there is something wrong with the module power supply levels OR
• the FPGA code has not loaded correctly
8.2 SDTI Input LED
The LED is green
• the SDTI signal is received correctly.
The LED is orange
• the input video standard is 625/25i but the signal is not a Nevion SDTI audio signal
The LED is red
• there is no input or the module is unable to lock to the signal.
8.3 EDH LED
The LED is green
• the SDTI signal is received correctly and has no errors in the EDH flags.
The LED is orange
