Posiflex JIVA HS-2310 - Manual (Page 16)

Part 16
constitute major difficulty for average user or obstacle by possibly
unintentional negligence even for PC veterans to accomplish such a task.
Therefore, OS installation into a system without preloaded OS is highly
discouraged. Posiflex shall not be responsible for any technical support to
questions arisen due to non-preloaded OS.
USING THE TOUCH TERMINAL
APPLICATION ENVIRONMENT
It is very important that you check the following operational guidelines:
Ventilation
This terminal must NOT be operated in an environment with restricted
ventilation. There must be at least 25 mm air clearance around any top or side
ventilation holes with a free flow of air around the unit at ALL times for the
installation.
Operating Environment
The equipment must not be operated or stored in extremes of both temperature
and humidity/moisture. (Operating range 0°C to 40°C and up to 80%
humidity – non condensing, max. wet bulb 26°C)
Power Supply
The operating voltage range of the power adaptor should cover the local power
supply for proper operation. The power cable, the power outlet and any power
fusing arrangements must conform to local safety regulations.
Please never do any connection / disconnection when system is still powered
on. Please always keep the external power adaptor in a free air circulation.
POWER ON/OFF CONTROL
Power Indicator
There is a power indicator LED at center of lower left rim of HS main body.
This LED lights up orange when external power is ready and turns to blue
when system power is turned ON.
Hardware Power Switch
The power switch located at left side of the main unit is a
tactile pushbutton switch. This switch controls the power
