4-4 Measurement in MANUAL mode with the log mode:
WARNING: this feature is only available if there is no Sequence downloaded in the
DO7010 (see chapter 5).To delete the loaded sequence; please refer to the DO7010-
PRO software manual.
Φ Set the Log mode (see section 4-1-4) and trigger a measurement with the green
push button on the battery pack front panel, or by making contact on the
specimen under test with the probes.
Φ Each of the measurements will be stored together with the range, current, date,
and time.
Φ To review the measured values:
– Press on the PARAM function key
– Select the LOG line
– Press on the Enter key
– Select the REVIEW line
– Press on the Enter key
– The LCD screen shows the values as follows:
- Scroll the values with the DOWN or UP arrows.
- Escape this menu with the ESC function key.
– Press on the PARAM function key
– Select the LOG line
– Press on the Enter key
– Select the DELETE line
– Press on the Enter key
– Confirm the delete by selecting the CONFIRM line
– Press on the Enter key.
– Select the CANCEL line to stop delete operation
– Press on the Enter key
LOG# Rx RANGE I DATE TIME
1 10.01 60 HI 19/07/04 13 :14
2 10.03 60 HI 19/07/04 13 :15
3 10.01 60 HI 19/07/04 13 :16
4 10.05 60 HI 19/07/04 13 :17
5 10.01 60 HI 19/07/04 13 :18
To delete all the saved measurements:
