Watson-Marlow PF22 - Manual (Page 31)

Operators Manual
PF22
PF22 OM EN 74-132-005 v1.02.doc Version: 1.02 Page 31 of 34
8.3 Print programs
Up to five programs can be stored in PF22, and a list of saved programs can be printed by means
of function 34.
The printing is to be started in the following way:
<3>+<4>+<ENT>, and the following display will be shown:
F34 PRINT PROGS (Y/N):_
F 1: VOLUME (ml): 50.50
press the <Y> key to confirm start of printing, and the printer will start.
Example of print-out:
* Flexicon PF22 V1.1 *
PROGRAM NO. 1
VOLUME (ml) 50.50
TUBE (mm) 6.5
VELOCITY (rpm) 200
ACCELERATION 35
REVERSE 1
BATCH SIZE 100
DELAY (sec) 1.1
SPECIFIC GRAVITY (g/ml) 1.0000
PROGRAM NO. 2
VOLUME (ml) 25.0
TUBE (mm) 5.0
Velocity (rpm) 250
ACCELERATION 28
REVERSE 0
BATCH SIZE 500
DELAY (sec) 1.0
SPECIFIC GRAVITY (g/ml) 1.0100
