ATA-171/172/171P/171M/171+/172+
User’s Guide
7.6.1 RPort Settings
7.6.1 Function
RPort Setting provides RPort Setting.
7.6.2 Instruction
Figure 1: FXS or Phone equipment
Figure 1
RPort Default: O. When setting ON, RPort settings will be active.
Provides ON and OFF modes
Submit [Button] Submit the change.
Reset [Button] Clear the change.
Figure 2: 2FXS equipment
Figure 2
RPort of Phone 1 Default: On. When setting ON, RPort settings will be active.
Provides ON and OFF modes
RPort of Phone 2 Default: On. When setting ON, RPort settings will be active.
Provides ON and OFF modes
Submit [Button] Submit the change.
Reset [Button] Clear the change.
7.6.3 Operate Instruction
Step 1: On the main page, select [SIP Settings RPort Settings], enter [RPort Setting] page, after
revising the information (e.g.: RPort: on) (See Figure 3), click [Submit].
