SS3GR24i/SS3GR48i Layer 3 Switch CLI Reference
117
diffserv classifier
Purpose Used to setup a classifier for the diffserv.
Syntax diffserv classifier<id>[src-mac <MAC>][dst-mac
<MAC>][vlan-id<vid>][dscp]
<value>][protocol <pro-num>][src-ip <ip>][dst-ip
<ip>][src-port
<port>][dst-port <port>]
Description To configure classifier for diffserv.
Parameters <id> src-mac
<MAC> Classifier Index for diffserv Source MAC
Address for classifier dst-mac
<MAC> Destination MAC Address for classifier vlan-
id
<vid> VLAN ID for classifier.
<value> 6-bits DSCP value in IP header for classifier.
<pro-num> 8-bits Protocol value in IP header for
classifier.
<ip> Source IP Address for classifier
<ip> Destination IP Address for classifier
<port> Source Layer 4 Port number for classifier.
<port> Destination Layer 4 Port for classifier.
Menu Quality of Service Configuration -> Classifier
Configuration
Restrictions Global configuration
Example usage:
Setup a classifier id of 23 and a source MAC of 00:11:22:33:44:55 for VLAN
40.
24P switch(config)# diffserv classifier 23 src-mac
00:11:22:33:44:55 vlan-id 40
