137
iMC-Panel-100
Operator’s Guide (for Imagestore 750s)
Audio Preview Menu
Figure 6-5 shows the iMC-Panel-100’s ‘Audio Preview’ menu:
Fig. 6-5: Audio Preview Menu
This menu allows you to select the source for the audio that is directed to the Imagestore 750’s
preview output.
Buttons
The ‘Audio Monitor’ menu and the ‘Audio Preview’ menu have a certain number of buttons that
depend on the configuration of the Imagestore 750 under control.
There are 11 source choices illustrated above:
The number of sources and the names of the sources are determined by the person who config-
ured the Imagestore 750. Consult your management if you need to know what the sources
mean.
The ‘Main Menu’ button returns you to the main menu.
If the required audio component is absent, the menu displays a message similar to the
following:
Waiting for configuration information, or this audio
output multiplexer is not defined in the audio template or
Configurator audio graph.
PGM Input PGM Input Post PGM Easyplay PGM Post Voiceover
PST Input PST Input Post PST Easyplay PST Post Voiceover
PGM Copy PGM Post AB Mix AES Voiceover Input
