26 October 2009 K2 Storage Area Network Installation and Service Manual 149
Restoring from a recovery disk image CD set
The Network Connections window opens.
b. Right-click a network connection and select Properties .
The …Connection Properties dialog box opens.
c. Click Configure .
The …Properties dialog box opens.
d. On the Power Management tab, uncheck all checkboxes, if they are not already
unchecked.
e. On a K2 Media Server, on the Advanced tab, select Power Server Option |
Properties and uncheck all checkboxes, if they are not already unchecked, then
click OK .
f. On the …Properties dialog box, click OK .
g. Repeat these steps on the remaining network connections in the Network
Connections window.
30. Install K2 Media Server software. Also install related software, such as SNFS, if
required for the latest upgrade. Refer to your latest K2 Release Notes for detailed
instructions.
31. You must active the Windows operating system within 30 days. Refer to
“Activating the Windows operating system” on page 151
The K2 Media Server is now restored to its factory-default state. However, you can
complete its configuration as part of a K2 SAN by using the K2 System Configuration
application.
Restoring from a recovery disk image CD set
The following procedure can be used on a K2 Media Server that needs all three
partitions on the system drive restored.
This procedure assumes that the image on the CD set is the system-specific image, for
the particular machine that you are restoring.
NOTE: At any step in this procedure if a message appears asking for disc/volume,
insert CDs as prompted until you can proceed to the next step.
1. Make sure that media access is stopped and that the K2 Media Server on which you
are working is not being used.
2. If you have not already done so, connect keyboard, monitor, and mouse to the K2
Media Server.
3. Insert the Recovery CD and restart the machine. If there is a problem restarting,
hold the standby button down for five seconds to force a hard shutdown. Then press
the standby button again to startup.
The machine boots from the disc. The Acronis startup screen appears.
4. At the startup screen, select True Image Server (Full Version) .
The Acronis True Image program loads.
The Acronis True Image main window appears.
