289 K2 Storage Area Network Installation and Service Manual 26 October 2009
Software Configuration
This page checks for the
software required to support
the roles you selected on the
previous page.
If software with Yes in the Required column reports as Not Installed, you
must first install it on the K2 Media Server before continuing. After
installing the software, click
Check Software . When all required
software reports as Installed, click Next .
Network Configuration
This page displays the
control network Ethernet
port, and allows you to
configure the FTP/
Streaming network Ethernet
port.
For systems with an optional
NH (FTP) server, the server
you ar now configuring does
not take the role of FTP
server, so configuring the
second port here for the FTP/
streaming network is not
required.
The top port is the port over which the K2 System Configuration
application is communicating with the K2 Media Server. If correctly
configured, it is already assigned the control network IP address, as
displayed on this page.
If the other port is not already configured correctly, select the other port
and click
Modify . A network configuration dialog box opens. Enter the
FTP/Streaming IP address and the subnet mask and click Apply .
Click Next .
On this page… Do this…
