72
M-Series Service Manual
6 July 2004
Chapter 4 Removing and replacing FRUs
Power supply removal
Access the power supply from the rear panel. Remove as illustrated.
Power supply installation
Remove
two
screws
Disconnect
power cord
Open handle
and slide out
1
2
3
1
3
2
Attach
two
screws
Slide in until seated
Close handle
