Panel Basics
Profile Family 181
Figure 87. Panel dialog box
1. The Type box shows the type of pictures: I for I-frame, B for Bidirectional,
and P for Predictive. B and P apply only to MPEG pictures. An I-frame
picture or Intra-picture is analogous in JPEG and MPEG and so applies to
both.
2. The Size box shows the number of bytes stored for the current field. The
more detailed the picture, the higher the number of bytes. Target
compression rate is set in the Edit Presets dialog box accessed from
Controller | Configure. See “Configuring a Controller” on page 165.
3. The Timecode box is th e current timecode of the selected clip. To configure
timecode, refer to “Setting Timecode” on page 177. For example, when you
use slow motion replays from several camera angles, the timecode can free
run or freeze. Clicking on the
Timecode box brings up the Go To Timecode
2. Size 3. Timecode
4. Play
6. Rewind
5. Stop
7. Record
8. Fast
9. Field
10. Normal
11. Loop
12. Bounce
13. PB/EE
14. Clip
Position Bar
15. Remove In
Mark
16. Set In
Mark
17. Trim to
In Mark
Forward
Selection
18. Trim from
Out Mark
19. Set Out
Mark
20. Remove
Out Mark
21. Group Name
22. Go to
Clip End
23. Forward
One Field
24. Back One
Field
25. Go to Clip
Beginning
26. Shuttle Bar
27. Shuttle Rate
28. Clip Name
Box
Box
1. Type
