Viewing an Audio Monitor for a Panel
Profile Family 189
Figure 90. Audio Monitor dialog box
3. To turn peak hold on or off, choose PeakHold | On or PeakHold | Off . By
default, peak hold is on. The peak indicators, the white bars in record level
controls, indicates the audio peak you are currently recording.
4. To show the record level controls, choose Levels | Show Record Level
Controls . To show play level controls, choose Levels | Show Play Level
Controls . To hide the level controls, choose Levels | Hide Level Controls .
5. To work the record and play level controls independently, choose Levels |
Independent Controls . To gang the controls, choose Levels | Ganged
Controls .
6. Click Close ( ).
Record Level Controls
Play Level Controls
Peak Indicators
Channel Indicators
Close Button
