Solution:
Basic course G3/Upgrade course
Die II
266/4
D02
SPGM
24 TOOL CALL 6 Z S300 ............................................... R3
25 L Z+100 M3
26 CYCL DEF 2.0 TAPPING
27 CYCL DEF 2.1 SET UP 2
28 CYCL DEF 2.2 DEPTH -12
29 CYCL DEF 2.3 DWELL 1
30 CYCL DEF 2.4 F300
31 CALL LBL 2
32 L Z+100 R0 F MAX M2
33 LBL 1
34 CYCL DEF 221 CARTESIAN PATTRN
Q225=+30 ................................................................. STARTNG PNT 1ST AXIS
Q226=+42 ................................................................. STARTNG PNT 2ND AXIS
Q237=+10 ................................................................. SPACING IN 1ST AXIS
Q238=+8 ................................................................... SPACING IN 2ND AXIS
Q242=5 ..................................................................... NUMBER OF COLUMNS
Q243=3 ..................................................................... NUMBER OF LINES
Q224=+0 ................................................................... ANGLE OF ROTATION
Q200=2 ..................................................................... SET UP CLEARANCE
Q203=-6 .................................................................... SURFACE COORDINATE
Q204=20 ................................................................... 2ND SET UP CLEARANCE
35 LBL 0
36 LBL 2
37 CYCL DEF 220 POLAR PATTERN
Q216=+50 ................................................................. CENTER IN 1ST AXIS
Q217=+50 ................................................................. CENTER IN 2ND AXIS
Q244=80 ................................................................... PITCH CIRCLE DIA.
Q245=+0 ................................................................... STARTING ANGLE
Q246=+360 ............................................................... STOPPING ANGLE
Q247=30 ................................................................... STEPPING ANGLE
Q241=12 ................................................................... NR OF REPETITIONS
Q200=2 ..................................................................... SET UP CLEARANCE
Q203=+0 ................................................................... SURFACE COORDINATE
Q204=20 ................................................................... 2ND SET UP CLEARANCE
38 LBL 0
39 END PGM 266 MM
