HEIDENHAIN TNC 426, TNC 430 119
5.4 Thr
ee-Dimensional T
ool Compensation
Example: Block format with rotary axes
1 L X+31.737 Y+21.954 Z+33.165
B+12.357 C+5.896 F1000 M128
L Straight line
X, Y, Z : Compensated coordinates of the straight-line end point
B, C : Coordinates of the rotary axes for tool orientation
F : Feed rate
M : Miscellaneous function
