SMA SB 3000TL - Manual (Page 50)

SB 4000TL-21 SB 5000TL-21
Operating range at AC power frequency 60 Hz 55 Hz to 65 Hz 55 Hz to 65 Hz
Power factor at rated power 1 1
Displacement power factor cos φ, adjustable 0.8 underexcited to 1
to 0.8 overexcited
0.8 underexcited to 1
to 0.8 overexcited
Feed-in phases 1 1
Connection phases 1 1
Overvoltage category as per IEC 60664-1 III III
* depending on the configured country data set
Efficiency
SB 4000TL-21 SB 5000TL-21
Maximum efficiency, η
max
97.0% 97.0%
European weighted efficiency, η
EU
96.4% 96.5%
11.2 General Data
Width x height x depth, without Electronic So-
lar Switch 490 mm x 490 mm x 185 mm
Width x height x depth, with Electronic So-
lar Switch 490 mm x 519 mm x 185 mm
Weight 26 kg
Length x width x height of the packaging 597 mm x 617 mm x 266 mm
Transport weight 30 kg
Climatic category in accordance with
IEC 60721-3-4 4K4H
Environmental category Outdoors
Pollution degree outside the enclosure 3
Pollution degree inside the enclosure 2
Operating temperature range -25°C to +60°C
Maximum permissible value for relative humid-
ity, non-condensing 100%
Maximum operating altitude above mean sea
level (MSL) 2,000 m
Typical noise emission 25 dB(A)
Power loss in night mode <1 W
11 Technical Data SMA Solar Technology AG
Operating Manual SB30-50TL-21-BE-en-11 50
