Maximum data volume per inverter with Speed-
wire/Webconnect 550 MB/month
Additional data volume when using the Sun-
ny Portal live interface 660 kB/hour
Topology Transformerless
Cooling method Convection
Degree of protection for electronics in accor-
dance with IEC 60529 IP65
Protection class in accordance with IEC 61140 I
Grid configurations* IT, Delta-IT, TN-C, TN-S, TN-C-S, split phase, TT
(if V
N_PE
< 20 V)
Approvals and national standards, as per
10/2014** AS4777:2005, CE, CEI 0-21, C10/11:2012,
DIN EN 62109-1, EN 50438:2013, G59/3,
G83/2, IEC 61727, IEC 62109-1,
IEC 62109-2, IEC 62116, NRS 97-2-1, PPC,
PPDS, RD 661/2007, RD 1699:2011, SI4777,
TOR D4, VDE 0124-100, VDE0126-1-1:2006,
VDE0126-1-1 / UTE C15-712-1, VDE-AR-
N 4105, VFR 2014
* IT, Delta-IT: When using in these systems, the grounding conductor monitoring must be deactivated and
an additional grounding connected to the inverter.
** EN 50438: does not apply to all national appendices of EN 50438
IEC 62109-2: This standard requires that either the multifunction relay in the inverter is used as fault
indicator or that the inverter is connected to Sunny Portal and that the fault alert is activated in
Sunny Portal.
NRS 97-2-1: This standard requires a separate label attached to the AC distribution board which
indicates the AC-side disconnection of the inverter in case of a grid failure (for further details, see
NRS 97-2-1, Sect. 4.2.7.1 and 4.2.7.2)
RD 661/2007, RD 1699:2011:Contact the Service for restrictions in specific regions(see Section 13,
page 55).
11.3 Protective Devices
DC reverse polarity protection Short-circuit diode
Input-side disconnection point Electronic Solar Switch, SUNCLIX DC connector
DC overvoltage protection Thermally monitored varistors
AC short-circuit current capability Current control
Grid monitoring SMA Grid Guard 3
Maximum permissible fuse protection for
SB 3000TL-21 25 A
11 Technical Data SMA Solar Technology AG
Operating Manual 51 SB30-50TL-21-BE-en-11
