SMA SB 3000TL - Manual (Page 52)

Maximum permissible fuse protection for
SB 3600TL-21 32 A
Maximum permissible fuse protection for
SB 4000TL-21 32 A
Maximum permissible fuse protection for
SB 5000TL-21 32 A
Ground-fault monitoring for SB 3000TL-21 Insulation monitoring: R
iso
> 625 kΩ
Ground-fault monitoring for SB 3600TL-21 Insulation monitoring: R
iso
> 550 kΩ
Ground-fault monitoring for SB 4000TL-21 Insulation monitoring: R
iso
> 500 kΩ
Ground-fault monitoring for SB 5000TL-21 Insulation monitoring: R
iso
> 400 kΩ
All-pole sensitive residual-current monitoring unit Available
11.4 Climatic Conditions
Installation in accordance with IEC 60721-3-3, Class 4K4H
Extended temperature range -25°C to +60°C
Extended humidity range 0% to 100%
Extended air pressure range 79.5 kPa to 106 kPa
Transport in accordance with IEC 60721-3-2, Class 2K3
Temperature range -25°C to +70°C
11.5 Equipment
DC connection SUNCLIX DC connector
AC connection Spring-cage terminal
Display LC graphic display
BLUETOOTH As standard
Speedwire/Webconnect data module As standard
RS485, galvanically isolated Optional
Multifunction relay Optional
SMA Power Control Module Optional
11.6 Torques
Upper enclosure lid screws 6 Nm ± 0.3 Nm
Lower enclosure lid screws 2 Nm ± 0.3 Nm
11 Technical Data SMA Solar Technology AG
Operating Manual SB30-50TL-21-BE-en-11 52
