Configuration and Operation
Page 42 Operating Instructions Powador 12.0 TL3-20.0 TL3
NOTE
You can also access the web server of the inverter via the Internet. To do this, additional settings of
your network configuration, particularly your Internet router, are required.
Note that communication with the inverter is carried out over an unsecured connection, particularly
in the case of a connection over the Internet.
Calling up the web server
↻ Configure the Ethernet interface.
↻ Connect the Ethernet interface.
1. Open an Internet browser.
2. In the address field of the Internet browser, enter the IP address of the inverter and open the site.
» The Internet browser displays the start screen of the web server.
After it has opened, the web server displays information about the inverter as well as the current yield data. The web
server enables the following measurement data and yield data to be displayed:
• Feed-in power • Generator power
• Status • Generator voltage
• Grid power • Unit temperature
• Grid voltage
In order to display and export yield data, proceed as follows:
Select the display period
1. Open the web server.
2. Select the display period by choosing either daily view, monthly view, yearly view or overview.
Filtering display data (daily view only)
1. Open the web server.
2. Select daily view.
3. To show or hide measured values, select or deselect the corresponding checkboxes in the “Select display” area.
Exporting data
1. Filter the display data if necessary.
2. Select the display period if applicable (daily, monthly, yearly or overview).
3. Click the “Export data” key.
4. Save the file.
