2.2.3 Connector Pin Assignments


2.2.3.1 SC2T2: Select COM2 Type Jumper


COM2 TYPE

SC2T2

RS-232 (Default)

1-5,2-6,3-7,4-8

RS-422 5-9,6-10,7-11,8-12

RS-485

5-9,6-10,7-11,8-12
