29
(such as main jet) fuel path and float chamber surface. The air enters into the carburetor through
air filter. Considering the intake can not be too much resistant and other factors, the filter can not
be too dense and therefore part of the air in the tiny impurities will enter into the carburetor
through the air cleaner.
Disassembly/reassembly：
First disassemble air cleaner, and disassemble the carburetor as shown on the above figure.
Gasket
Stud
Gasket
Carburetor
Thermal baffle
Gasket
