Setup Utility Menu Screens 9-21
Copyright © 2001, 2002, 2007 by LSI Logic Corporation. All rights reserved.
Table 9.10 describes the Advanced Device Properties menu fields.
Table 9.10 Advanced Device Properties Field Descriptions
Field Description
Maximum INT 13h
Devices for this
adapter The maximum number of devices attached to the adapter for which to install a pre-
OS I/O interface. The specified number of devices in the adapter’s device scan
order list will have an I/O interface installed. (An installed I/O interface is defined
as Int13H.) X86 platforms allow a maximum of 24 Int13h devices per system.
Therefore, fewer than the specified number of Int13h devices may be installed. The
default for X86 is 24 devices, with a range of 0–24 allowed.
Maximum Target
Spinups The maximum number of targets that can simultaneously spin up. The IOC must
delay by the time indicated in the spin-up delay field before it starts spin-up of the
next set of targets. A value of 0 in this field is treated the same as a value of 1.
IO Timeout for
Block Devices The time, in seconds, (0–999, 0 = no-timeout) that the host uses to timeout I/Os
for the following devices with non-removable media:
•
SCSI Device Type 00h - Direct Access
•
SCSI Device Type 04h - Write Once
•
SCSI Device Type 07h - Optical
•
SCSI Device Type 0Eh - Simplified Direct Access
IO Timeout for
Block Devices
(Removable) The time, in seconds, (0–999, 0 = no-timeout) that the host uses to timeout I/Os
for the following devices with removable media:
•
SCSI Device Type 00h - Direct Access
•
SCSI Device Type 04h - Write Once
•
SCSI Device Type 05h - CD-ROM
•
SCSI Device Type 07h - Optical
•
SCSI Device Type 0Eh - Simplified Direct Access
IO Timeout for
Sequential
Devices The time, in seconds, (0–999, 0 = no-timeout) that the host uses to timeout I/Os
for the following devices:
•
SCSI Device Type 01h - Sequential Access
IO Timeout for
Other Devices The time, in seconds, (0–999, 0 = no-timeout) that the host uses to timeout I/Os
for devices other than the following:
•
SCSI Device Type 00h - Direct Access
•
SCSI Device Type 01h - Sequential Access
•
SCSI Device Type 04h - Write Once
•
SCSI Device Type 05h - CD-ROM
•
SCSI Device Type 07h - Optical
•
SCSI Device Type 0Eh - Simplified Direct Access
LUNs to Scan for
Block Devices Controls LUN scans for the following devices with non-removable media:
•
SCSI Device Type 00h - Direct Access
•
SCSI Device Type 04h - Write Once
•
SCSI Device Type 07h - Optical
•
SCSI Device Type 0Eh - Simplified Direct Access
LUN 0 Only: Scan only LUN 0.
All: Scan all LUNs.
