5 Mega-pixel Outdoor IR PoE IP Camera
ICA-3550V
10
■ Auto MDI/MDI-X supported
■ Supports both IPv6 and IPv4 protocols
■ RTSP / UPnP / 3GPP / HTTPS protocols selectable
¾ Easy Installation & Management
■ ONVIF compliant for interoperability
■ Built-in 35 IR Illuminators, effective up to 25 meters
■ IP66 outdoor classifications with cable management bracket for rigorous environment
■ Built-in Samba client for NAS
■ 3GPP for 3G mobile remote applications
■ Micro SD card for local video recording supported
■ Digital Input/Output for integration with sensors and alarms
■ Cam Viewer 3 central management software supported
1.4 Product Specifications
Model ICA-3550V
Camera
Image Device 1/3.2" 5 mega-pixel progressive scan CMOS Sensor
Lens
Vari-focal 3~10.5 mm, DC auto-iris
Mechanical IR-cut filter
Angle of view:
Horizontal: 25.49~85.02 degrees
Vertical: 19.09~65.47 degrees
Min Illuminator 0 lux @ F1.4
IR Illumination LED
IR LED*35, 850nm
Built-in IR illuminators, effective up to 25 meters
Effective Pixels 2592 x 1944 pixels
Video Encoder H.264 / MPEG-4 / M-JPEG
Video Profile
H.264: 2592 x 1944 / 1080P / 720P / QXGA / UXGA / 1280 x 960 / VGA
/ QVGA / QCIF
M-JPEG: 2592 x 1944 / 1080P / 720P / QXGA / UXGA / 1280 x 960 /
VGA / QVGA / QCIF
MPEG4: VGA / QVGA / QCIF (Only for 3GPP)
Frame Rate
5MP up to 15fps
Full HD up to 30fps
Image Setting
Brightness, sharpness, contrast, AGC, night mode
text, time and date overlay
Streaming Simultaneous multi-profile streaming
M-JPEG streaming over HTTP
Supports 3GPP mobile surveillance
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4 / H.264)
Audio
Audio Streaming Two-way audio
Audio Encoder RTSP: G.711 / G.726
