Philips AVENT SCD620/05 - Manual (Page 23)

Removing the rechargeable battery
Note: We strongly advise you to have a professional remove the
rechargeable battery.
Only remove the rechargeable battery when you discard the appliance.
Make sure the battery is completely empty when you remove it. Only the
parent unit includes a battery.
Procedure:
1 Remove the 2 rubber feet at the bottom of the parent unit.
2 Remove the 2 screws that are now visible at the bottom of the parent
unit.
3 Put the antenna in upward position and remove the screw in the back
housing that is now visible.
4 Remove the back housing from the front housing by forcing a screwdriver
in between them.
5 Disconnect the battery connector cable (black-white-red cable).
6 Remove the 4 screws from the battery holder.
7 Remove the battery.
Guarantee and support
If you need information or support, please visit www.philips.com/support or
read the separate worldwide guarantee leaflet.
Frequently asked questions
This chapter summarizes the most common problems you could encounter
with the appliance. If you are unable to solve the problem with the
information below, visit www.philips.com/support for a list of frequently
asked questions or contact the Consumer Care Center in your country.
HOW TO USE / CONNECTING THE UNITS
Question Answer
Why does the power-on
light of the baby unit
not go on when I switch
on the unit?
Perhaps the baby unit is not connected to the mains. Connect the baby unit
to the mains. Then set the on/off switch of the baby unit upwards to the ON
position to establish connection with the parent unit.
Why doesn't the parent
unit charge when I plug
it in?
Perhaps the adapter is not plugged in properly. Make sure the adapter is
plugged into the wall socket properly.
The parent unit may already be fully charged. The battery status light will
be green when the battery is fully charged and the device is connected to
the mains power.
Why doesn’t the baby
unit charge when I plug
it in?
The baby unit does not have a charging function. The baby unit only works
when it is connected to the mains.
23 English
