About your monitor
USB ports
• 1 super speed USB 10 Gbps (USB 3.2 Gen2) Type-C upstream (video and
data) - rear
• 1 super speed USB 10 Gbps (USB 3.2 Gen2) Type-C upstream (data only) -
rear
• 2 super speed USB 10 Gbps (USB 3.2 Gen2) Type-C downstream - bottom
• 5 super speed USB 10 Gbps (USB 3.2 Gen2) Type-A downstream - rear (4)
and bottom (1)
Power Charging Port - the port with
battery icon; supports up to 2 A
fast-charging capability if the device is BC1.2 compatible.
NOTE: Super speed USB 10 Gbps (USB 3.2 Gen2) functionality requires
a super speed USB 10 Gbps (USB 3.2 Gen2)-capable computer.
NOTE: The USB ports on the monitor work only when the monitor is
turned On or in Standby mode. If you turn Off the monitor and then
turn it On, the attached peripherals may take a few seconds to resume
normal functionality.
A6
D+
B6
D+
A7
D-
B7
D-
A8
SBU1
B8
SBU2
A9
VBUS
B9
VBUS
A10
RX2-
B10
RX1-
A11
RX2+
B11
RX1+
A12
GND
B12
GND
