Monitor specifications – Lenovo ThinkCentre Tiny-In-One 24 Gen 5 23.8" Multi-Touch Monitor with Webcam User Manual
Page 37
Monitor specifications
Table 3-1. Monitor specifications for type-model TIO24Gen5/12NA-GAR1-WW
Dimensions
Depth
207.57 mm (8.17 in.)
Height
539.57 mm (21.24 in.)
Width
539.80 mm (21.25 in.)
Stand
Tilt
Range: -5
o
~23.5
o
Swivel
Range: -45°+45°
Pivot
Range: -5°~90°
Lift
Range: 155 mm
VESA mount
Supported
100 mm x 100 mm (3.94 in. x 3.94 in.)
Viewable image size
605 mm (23.8 in.)
Maximum height
296.46 mm (11.69 in.)
Maximum width
527.04 mm (20.74 in.)
Pixel pitch
0.2745 mm × 0.2745 mm (0.01 in.)
Power input
Power consumption
Note:
Power
consumption figures are
for the monitor and the
power supply combined
Supply voltage
20VDC
Max supply current
4.5 A
Max Consumption
34 W (max)
Typical Consumption
14 W (typ)
Standby/Suspend
<0.5 W
Off
<0.3 W
DP
Interface
DP
Input signal
VESA TMDS (Panel Link™)
Horizontal addressability
1920 pixels (max)
Vertical addressability
1080 lines (max)
Clock frequency
205 MHz (max)
HDMI
Interface
HDMI
Input signal
VESA TMDS (Panel Link™)
Horizontal addressability
1920 pixels (max)
Vertical addressability
1080 lines (max)
Clock frequency
205 MHz (max)
Chapter 3.Reference information 3-4
