Recording
54
3.3K 6:5
For projects using 2x anamorphic Super 35 lenses for a target deliverable of 2.39:1. Negates necessity
of cropping 4:3 footage and fulfills 4K mandates.
Active Image Area
(Photo sites)
3328 x 2790
Active Image Area
(Dimensions)
20.2 x 16.9 mm / 0.796 x 0.693“
Image Circle
Ø
26.4 mm / 1.039“
Recording Resolutions
3.3K (3328 x 2790)
3.3K (3328 x 2790)
4K 2.39:1 Ana. 2x
(4096 x 1716)
3K 1:1
3K 1:1 was designed for shooting with 2x anamorphic lenses for a target deliverable of 2:1, fulfilling 4K
mandates.
Active Image Area
(Photo sites)
3072 x 3072
Active Image Area
(Dimensions)
18.7 x 18.7 mm / 0.737 x 0.737“
Image Circle
Ø
26.4 mm / 1.041“
Recording Resolutions
3K (3072 x 3072)
3K (3072 x 3072)
3.8K 2:1 Ana. 2x
(3840 x 1920)
2.7K 8:9
For projects shooting with 2x anamorphic lenses for a target deliverable of 16:9, fulfilling 4K mandates.
Desqueeze applied in-camera.
Active Image Area
(Photo sites)
2743 x 3086
Active Image Area
(Dimensions)
16.7 x 18.8 mm / 0.656 x 0.738“
Image Circle
Ø
25.1 mm / 0.988“
Recording Resolutions
UHD 16:9 Ana. 2x
(3840 x 2160)
2K 16:9 S16
2K 16:9 S16 mimics the traditional Super 16 format for use with Super 16 lenses or as an in-camera
center crop.
Active Image Area
(Photo sites)
2048 x 1152
Active Image Area
(Dimensions)
12.4 x 7.0 mm / 0.490 x 0.276“
Image Circle
Ø
14.2 mm / 0.561“
Recording Resolutions
2K (2048 x 1152)
For additional information please see
