7.
SATA 6Gb/s ports
The SATA 6Gb/s ports allow you to connect SATA devices such as optical disc drives
and hard disk drives via a SATA cable.
A
B
SATA6G_E34
SATA6G_E12
A
B
GND
RSATA_TXP
RSATA_TXN
GND
RSATA_RXN
RSATA_RXP
GND
GND
RSATA_TXP
RSATA_TXN
GND
RSATA_RXN
RSATA_RXP
GND
Before creating a RAID set, refer to the
RAID Configuration Guide. You can download
the
RAID Configuration Guide from the ASUS website.
