2-8 Chapter 2: Basic Installation
Chapter 2
3. Install your M.2 to your M.2 slot. The steps may differ between installing M.2 of
different lengths, please refer to the different types and their installation steps below:
• To install an M.2 to M.2_1, M.2_2 and M.2_4 slot
For 2280 length
A. Rotate and adjust the M.2 Q-latch so that the handle points away
from the M.2 slot.
B. Install your M.2 to the M.2 slot.
C. Rotate the M.2 Q-Latch clockwise to secure the M.2 in place.
For 2242, 2260 length
A. Install the bundled screw stand to the M.2 length screw hole you wish
to install your M.2 to.
B. Install your M.2 to the M.2 slot.
C. Secure your M.2 using the bundled screw stand’s screw.
