107
Product Manual WebPAM PROe - System Configuration
i
MportiNg a
C
oNFiguratioN
s
Cript
You can write a CLI configuration script to automatically configure your Vess R2600 subsystem. The script
must be a plain, non-encrypted text file. From there, you can import the script from the Host PC and perform the
configuration automatically.
Cautions
Do NOT attempt to write or modify a configuration script until you
receive guidance from Technical Support.
Importing a configuration script overwrites the current settings on
your Vess R2600 subsystem.
Or you can save the configuration from one Vess R2600 RAID subsystem, export it, and then import it to
automatically configure your other Vess R2600 RAID subsystems. To import a configuration script:
1. Click the Administration tab.
2. Click the Import/ E xport icon.
3. Click the Import option.
4. Choose Configuration Script from the Type drop-down menu.
5. Click the Browse button and navigate to the configuration script and click the OK button.
6. Click the Next button.
The system verifies that the file is a valid configuration script and displays any errors or warnings.
7. Click the Submit button to continue.
8. In the Confirmation box, type the word “ confirm ” in the field provided and click the Confirm button.
The configuration script is imported and applied automatically.
