ENGLISH
19
ANALOG AUDIO
The T 758 has six analog audio inputs including 7.1 input. These analog
inputs - Stereo 1, Stereo 2, Stereo 3, Stereo Front, Audio Front and 7.1 CH
INPUT can be variably assigned to each Source.
If “Off’ is selected, no incoming analog audio signal is selected by the
particular Source.
NOTE
An incoming digital signal present at the assigned digital input will always
take precedence over the assigned analog audio input, even if both are
present. To maintain the analog audio input for the particular Source, select
“Off” at the “Digital Audio” setting of the same “Source” menu.
ANALOG GAIN
Gain adjustment allows all sources to play back at the same volume level so
you don’t need to adjust the volume every time a new source is selected. It
is generally preferable to reduce the level of the loudest source rather than
making louder the softer sources.
Scroll to “Analog Gain”, press [ S ] and then [ D/F ] to step through the
desired level from -12dB to 12dB.
DIGITAL AUDIO
To take advantage of the T 758’s high performance surround and digital
audio circuitry, it is advisable that its Digital Audio inputs are selected.
There are various types of Digital Audio input for the T 758. These are HDMI,
BluOS, Optical and Coaxial digital inputs. Another option is “Off” whereby
no incoming digital audio signal is selected by the particular Source.
The following are the sets of assignable Digital Audio input:
HDMI $ HDMI 1, HDMI 2, HDMI 3
Optical $ Optical 1, Optical 2, Optical Front
Coaxial $ Coaxial 1, Coaxial 2
BluOS
NOTE
An incoming digital signal present at the assigned digital input will always
take precedence over the assigned analog audio input, even if both are
present. To maintain the analog audio input for the particular Source, select
“Off” at the “Digital Audio” setting of the same “Source” menu.
VIDEO INPUT
All three HDMI sources can be assigned as video input to a particular Source.
Another option is “Off” wherein the particular Source is prompted not to select
any Video input.
HDMI $ HDMI 1, HDMI 2, HDMI 3
Previous $ Display or retain preceding video.
NOTE
The T 758 also supports HDMI features that include compatibility with a
broad range of 3D and HD digital video sources and displays.
A/V PRESET
A particular Source can be assigned a stored Preset. The parameters set up
in the selected Preset number will be adopted into the particular Source it
is assigned (Please refer to the separate section on “A/V Presets” for further
understanding of Preset settings).
A Source could be assigned a Preset number ranging from Preset 1 to 5.
If it is desired not to assign the particular Source a Preset setting, select “None”.
TRIGGER OUT
The Trigger Out for a particular Source is dependent upon the
configurations done in a separate menu on Trigger Setup (See “Trigger
Setup” below).
For “Trigger Out” to become enabled and assignable at “Source Setup”
menu, make sure to carry out or note the following beforehand
• In the separate “Trigger Setup” menu, assign “Trigger 1 Out” to “Source
Setup”.
• “Trigger Out” option will only be “None” if at the separate “Trigger Setup”
menu, “Trigger 1 Out” is assigned to either ‘Main” or “Zone 2”.
Set “Trigger Out” to “Trigger 1” to activate Trigger Out or “None” to disable it.
OPERATION
USING THE T 758 – SETUP MENU
