ENGLISH
5
INTRODUCTION
GETTING STARTED
WHAT’S IN THE BOX
Packed with your T 758 you will find
• Quick Setup Guide
• BluOS Kit containing USB Hub, Wi-Fi Dongle, Bluetooth USB Micro Adapter and USB to USB Cable
Extender
• AVR 4 remote control with 2 AA batteries
• BluOS-Ready Flyer/Bluesound player
• ZR 7 zone remote control with 3V CR2025 battery
• Measurement microphone with USB Mic adapter and phone jack adapter
• Detachable mains power cord
SAVE THE PACKAGING
Please save the box and all of the packaging in which your T 758 arrived. Should you move or
otherwise need to transport your T 758, this is by far the safest container in which to do so. We’ve seen
too many otherwise perfect components damaged in transit for lack of a proper shipping carton, so
please: Save that box!
INITIAL SETUP
Before you make the first connection to your T 758, you should have the arrangement of your
listening room/home theater components and furniture mapped out, at least initially. Unfortunately, a
discussion of the vital questions of loudspeaker placement and listening/viewing positions is beyond
our scope here.
CHOOSING A LOCATION
Choose a location that is well ventilated (with at least several inches to both sides and behind), and
that will provide a clear line of sight, within 25 feet/8 meters, between the T 758’s front panel and your
primary listening/viewing position - this will ensure reliable infrared remote control communications.
The T 758 generates a modest amount of heat, but nothing that should trouble adjacent components.
It is especially important that sufficient ventilation be provided.
DEFAULT SOURCE SETTINGS
The following table lists the default SOURCE settings. Note that the Audio input settings show both
digital and analog audio input. Digital input will always take precedence over analog audio input even
if both are present.
Source Audio Input Video Input
Source 1 HDMI 1 / Audio 1 HDMI 1
Source 2 HDMI 2 / Audio 2 HDMI 2
Source 3 HDMI 3 / Audio 3 HDMI 3
Source 6 BluOS Off
Source 7 7.1 Channel Input Off
Front Input Optical Front Input/ Audio Front Input Off
Media Player Audio Front MP
To modify the above default settings and for a better understanding of source setting and
combinations, please refer to the item about “SOURCE SETUP” in the “USING THE T 758 - SETUP MENU”
segment of the “OPERATION” section.
