SSM
Digital Hybrid Wireless ® Micro Transmitter
SSM, SSM-941, SSM/E01, SSM/E01-B2, SSM/E02, SSM/E06, SSM/X
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Fill in for your records:
Serial Number:
Purchase Date:
Quick Start Steps
1) Install a good battery and turn power on (see pages 5
and 8).
2) Set the compatibility mode to match the receiver (see
page 9).
3) Connect the signal source and adjust input gain for
optimum modulation level (see page 10).
4) Set Step Size and frequency to match receiver (see
pages 8 and 9). Also refer to the receiver manual for
the RF scanning procedure to find a clear operating
frequency.
5) Turn on the receiver and verify that solid RF and
audio signals are present (see receiver manual).
WARNING: Moisture, including talent’s sweat,
will damage the transmitter. Wrap the SSM
in a plastic bag or other protection to avoid
damage.
