Setup Screens
DOWN Button Menu
Hold the DOWN button while powering up the unit.
Then press the AUDIO button repeatedly to scroll through the
following settings. Use the UP and DOWN arrows to select the available options under each setting.
•
rc
- remote control operation; selections:
on, oFF
•
PbAc
- power-back-on after power loss; selections:
0
(stay turned off),
1
(turn back on)
•
bL
- back light duration; selections:
5
(minutes),
30
(seconds),
on
(always on)
UP Button Menu
Hold the UP button while powering up the unit.
Then press the AUDIO button repeatedly to scroll through and se-
lect the following settings (bulleted). Use the UP and DOWN arrows to select the available options under each setting.
•
CP
- compatibility mode; press the UP and DOWN arrows to select one of the following:
CP nHb
Nu Hybrid mode
CP 3
Mode 3 (contact the factory for details)
CP IFb
IFB Series mode; IFBR1/1a receivers
•
Pr
- RF power output; selections: 25, 50 (10 mW is the only option for E02)
•
In
- Input configuration; press the UP and DOWN arrows to select one of the following:
In dYn
bIAS 0, rES 0; use for dynamic microphones; positive polarity
In 152
bIAS 4, rES 0; same as otH; listed for easy selection on Lectrosonics 152 and similiar mics;
positive polarity
In SEn
bIAS 4, rES 0; same as otH; listed for easy selection on Sennheiser MKE 2 and similiar mics;
positive polarity
In SEt
Press the AUDIO button for manual setup of input for explicit control over bias voltage, input
resistance and audio polarity. Press the AUDIO button to select the following
parameters, then use the UP and DOWN arrows for each item to set the values.
bIAS - bias voltage on the input; selections
0
,
2
or
4
rES - input impedance; selections:
0
(300 ohms),
Lo
(approx. 4 k ohms) or
HI
(approx. 100 k ohms)
AP - audio polarity (aka “phase”); selections:
P
for positive,
n
for negative (reversed)
NOTE: When you press AUDIO after setting the polarity, the screen will leave this submenu and return
to the
In
menu. To return to this submenu, press AUDIO repeatedly and scroll through the list again.
In otH
bIAS 4, rES 0; same as CoS but audio phase is not reversed; for various mics; positive polarity
In L In
bIAS 0, rES HI; use for line level input (See Line Input Wiring and Use on page 11); positive polarity
In dPA
bIAS 4, rES Lo; use for DPA lavaliere and similar mics; negative polarity
In b6
bIAS 2, rES 0; use for Countryman B6 and similar mics; positive polarity
In CoS
bIAS 4, rES 0; phase reversed; use for Sanken COS-11, M152 and similar mics; negative polarity
In PSA
bIAS 4, rES Lo; use for Point Source Audio lavaliere and similiar mics; negative polarity
•
StP
- Frequency tuning step size in kHz; selections: 25 kHz or 100 kHz
