– 21 –

TROUBLESHOOTING

TROUBLE

CAUSES

WHAT  TO  DO

1. Machine has no output

with machine switch in
CV mode.

2. Machine has minimum

output and no control.

a. Electrode or work lead loose or

broken.

b. No generator output.

c.

CR4 is not working, or no input to
CR4.

d. Protective circuits operating due to

output short circuit.

e. Broken or loose wiring connec-

tions.

f. Defective P.C. Board

a. No shunt field voltage.

b. Excessive current, thermal shut-

down.

c.

Open in feedback circuitry.

d. Voltage adjust potentiometer circuit

open or misconnected.

e. Defective P.C. Board.

a. Repair Connection.

b. Refer to quick check procedure for

generator only.

c.

Refer to procedure for Checking the
Cold Tip Contactor (CR4).

d. Turn engine off. Remove short

circuit.

e. Broken or loose connections from

WFM to control panel and engine
welder. Refer to wiring diagram to
check.

f.

Refer to P.C. Board Troubleshooting
Procedure.

a. In CV mode, check for 10-60 VDC

across pin 8 of J3 and pin 1 of J4 on
WFM P.C. Board.
-- Check for loose or broken

connections in wiring harness.

-- Refer

to

P.C.

Board

Troubleshooting Procedure.

b. Remove load and allow machine to

cool down. If output returns after
cool down, reduce output or duty
cycle.
-- Check for continuity at quick con-

nects between leads 609 and 608
inside the WFM.

-- Check wiring harness with these

connections.

-- Check continuity of the thermostat

located on the generator negative
brushholder.

c.

Check in-line connector, P.C. Board,
and wiring harness plugs, especially
leads 667 and 621.

d. Refer to procedure for checking

Voltage Control Potentiometer on
Machine. Check wiring of lead num-
bers 75, 76, and 77.

e. Refer to P.C. Board Troubleshooting

Procedure.
