B-16 OPERATION B-16
The MAXsa™ 10 has eight available memory loca-
tions for storing procedural information. Each location
will store the following information:
• Weld Mode
• Amperage(or WFS)
• Voltage
• Frequency
• Balance
• DC Offset
• Arc Start options
• Arc End Options
NAMING A SAVED PROCEDURE
Procedures stored in memory can be given a name
that the user will easily recognize such as “Root
Pass”‘ “Fill Pass” or “Cap Pass’. As with the Lockout
Option. this option is only available through the use of
Weld Manager.
MULTI PROCEDURE WELDING
The MAXsa™ 10 CONTROLLER can do “On-The-Fly”
welding changes with multiple weld procedures by
using the Memory Panel. While welding, any Memory
location can be accessed, and the parameters stored
in that memory location will be switched in while
actively welding.
NOTE: This can only be done with Memory loca-
tions that have the same Weld Mode.
While welding, any Memory location trying to be
accessed with a different Weld Mode than the one
currently being used will be ignored and an error mes-
sage will be displayed. Up to eight different weld pro-
cedures can be used while actively welding by using
all of the memory locations, as long as each location
utilizes the same Weld Modes.
Memory saving can be optionally disabled using
Lockout Levels. If the user attempts to save a proce-
dure to memory location that is locked, the Mode
Select Panel will briefly display "Memory Save is DIS-
ABLED!". Presently, Memory Panel Lockout Levels
can only be accessed through Weld Manager.
MAXsa™ 10 CONTROLLER
USING THE MEMORY OPTION
