11 ‘05-‘09 Tacoma (W/O Hitch) - 3” Kit 5603
5. Remove two nuts and fuel line brackets from driver
side body.
6. Remove bolt and brake line bracket from driver side
frame.
Front
Rear
Fuel Lines
Bracket
Nut
Nut
Fuel Lines
Frame
Brake Line
Bracket
Bolt
Rear of Vehicle
1. Fuel filler
a. Remove fuel filler cap.
b. Loosen two hose clamps and disconnect vent
hose connector.
c. Remove bolt and fuel filler from vehicle.
WARNING
Use extreme caution when working near the fuel lines
and the fuel tank. Clean up spilled fuel immediately. A
spark could cause an explosion or fire resulting in seri-
ous personal injury and property damage.
Fuel Filler
Cap
Body
Fuel Filler
Vent Hose
Clamp
Front
Fuel Tank
Fuel Filler
Bolt
Frame
