7 7.10 Settings Up the Communication
7-72 bizhub 161f
Us
in
g th
e Uti
lit
y
Mod
e
Chap
ter
7
7.10 Settings Up the Communication
From the “COMM.SETTING” menu, various functions are available for specifying
communication settings.
Specifying the Setting for “TONE/PULSE”
There are two types of telephone dialing systems: tone dialing (PB) and pulse
dialing (DP10pps or DP20pps). Faxes cannot be sent if this machine is not set to
the system used by your telephone line. Select the correct setting after checking
which type of dialing system is used.
To specify the telephone dialing system
1 Press the [Utility] key nine times.
The first screen of the Utility mode
appears.
2 From the 10-Key Pad, press the
[1] key.
No. COMM.SETTING Characteristic/Description
1 TONE/PULSE This function can be used to specify the dialing system. If this function is
not correctly set to the type of dialing system used, faxes cannot be sent.
Select the correct setting after checking which type of dialing system is
used by your telephone line.
2 LINE MONITOR This function can be used to set the volume when monitoring
communication to “HIGH”, “LOW” or “OFF”.
• The manufacturer’s default setting is “LOW”.
3 PSTN/PBX This function can be used to set whether the connected telephone wiring
is a public switched telephone network (PSTN) or a private branch
exchange (PBX).
For a PBX system, the outside line access number (or extension number)
must be specified.
